Ti-4Al-0.005B Titanium Alloy
Ti-4Al-0.005B Alloy is a medium-strength α-type titanium alloy, which contains 4% α-stabilizing element Al and trace element B. Among them, Al makes the alloy solid solution strengthened, and B can refine the alloy structure . This alloy cannot be strengthened by heat treatment and is usually used in an annealed state. The alloy has excellent welding performance and corrosion resistance, and can be processed by traditional pressure processing and mechanical processing. Its semi-finished products mainly include bars, forgings, plates and wires.
Density ρ=4.43g/cm³
| Physical and chemical properties of Ti-4Al-0.005B | ||
| Density /g.cm-3 | Linear expansion coefficient /10-6K-1 | Specific heat capacity /10-6K-1 |
| 4.43 | 9.28(20~100℃) | 523(100℃) |
Ti-4Al-0.005B Titanium Alloy chemical composition (mass fraction) %
| Technical Standard | Alloy Element | Impurities≤ | ||||||||
| Ti | Al | B | Fe | C | N | H | O | Other elements | ||
| Single | Total | |||||||||
| GB/T 3620.1 | Balance | 3.3~4.7 | 0.005 | 0.3 | 0.1 | 0.04 | 0.015 | 0.15 | 0.1 | 0.4 |
Application of Ti-4Al-0.005B Titanium Alloy
Ti-4Al-0.005B Alloy can be used as a structural material in seawater corrosive environment and has been successfully applied in the shipbuilding industry. The main application parts on ships are pressure hulls, torpedo launchers, power plants, etc. In addition, because the alloy has a certain strength and excellent corrosion resistance, it can also be widely used in chemical and other corrosion resistant projects.
