Fatigue performance of Titanium Rod / Bar
| Rotational bending fatigue limit of Ti Gr3 Bars / Ti Gr3 Rods | |||||||
| Material | Form | State | θ/℃ | kt | R | N/Week | σD/MPa |
| Ti | Bars / Rods | Annealed | 20 350 400 450 |
1 | -1 | 107 | 274 162 144 112 |
Tensile Properties and Impact performance of Ti Rod / Bar
| Tensile Properties of Ti Bars / Ti Rods | |||||||||
| Material | Form | d/mm | State | Sampling direction | θ/℃ | σb/MPa | σp0.2/MPa | δ/% | ψ/% |
| Ti | Forged Bars | 14 | Annealed | L | -253 -196 20 100 150 200 |
1177 951 490 412 343 294 |
1079 735 373 294 245 206 |
10 20 30 30 30 30 |
35 48 55 55 55 55 |
| Impact performance of Ti Bars / Ti Rods | ||||||
| Material | Form | d/mm | State | Sampling directio | θ/℃ | αKU/kJ·m-2 |
| Ti | Forged Bars | 14 | Annealed | L | -253 -196 20 |
58.8 78.4 98.1 |
Durability and Creep Properties of Ti Bars / Ti Rod
| High temperature durability of Ti Bars / Ti Rods | ||||||
| Material | Form | d/mm | State | Sampling directio | θ/℃ | σ100/MPa |
| Ti | Bars | 20 | Annealed | L | 350 400 450 |
191 176 98 |
| High Temperature Creep Properties of Ti Gr3 Bars / Ti Gr3 Rods | ||||||
| Material | Form | d/mm | State | Sampling directio | θ/℃ | σ0.2/100/MPa |
| Ti | Bars | 20 | Annealed | L | 350 400 450 |
93 68 29 |
Elastic properties of Ti Bars / Ti Rods
| Tensile elastic modulus of Ti Gr3 Bars / Ti Gr3 Rods | ||||||
| Material | Form | d/mm | State | Sampling directio | θ/℃ | E/GPa |
| Ti | Forged Bars / Rods | 14 | Annealed | L | 20 100 150 200 |
107.9 102 93.2 88.2 |
Mechanical properties of Ti Bars / Ti Rods
| Material | Form | State | δ or d/mm | Sampling direction | Room temperature | ||||||
| σb/MPa | σP0.2/MPa | δ 5/% | ψ/% | α/(°) | αKU/kJ·m-2 | HBS | |||||
| ≥ | |||||||||||
| Ti | Rod/Bar | Annealed | 8~90 | L | ≥440 | 320 | 18 | 30 | - | - | - |
