FORMS WE CAN PROVIDE

Titanium Sheet/Plate
Titanium Rod/Bar
Titanium Wire

Titanium

Industrial pure titanium refers to several kinds of unalloyed titanium with different impurity contents such as Fe, C, N, and O. It cannot be strengthened by heat treatment, has excellent formability, and is easy to weld and braze. Used to manufacture various non-load bearing parts, the long-term working temperature can reach 300℃.

Physical and chemical properties of industrial pure Titanium

Density Melting temperature range
ρ=4.50 g/cm-3 1640~1670℃
Electrical properties Room temperature resistivity Magnetic properties
ρ=0.487μΩ.m Non-magnetic

Classification and characteristics of Titanium and Titanium Alloys

Grade Alloy
Element		 Impurities≤
Ti Fe Si C N H O others
single total
Ti Gr1 Base 0.15 - 0.1 0.03 0.015 0.15 0.1 0.4
Ti Gr2 Base 0.25 - 0.1 0.03 0.015 0.2 0.1 0.4
Ti Gr3 Base 0.3 - 0.1 0.05 0.015 0.25 0.1 0.4
Ti Gr4 Base 0.4 - 0.1 0.05 0.015 0.3 0.1 0.4

Grade comparison and strength level of industrial pure Titanium

Grade Similar Grade Nominal chemical composition Operating temperature /℃ Intensity level /MPa
TA0 Gr.1 Ti 300 ≥280
TA1 Gr.2 Ti 300 ≥370
TA2 Gr.3 Ti 300 ≥440
TA3 Gr.4 Ti 300 ≥540

Choices of Titanium

Application of Titanium and Titanium Alloys

Application field Use characteristics of materials Application
Aircraft Industry Jet Engine Below 500℃, with high yield strength/density ratio and fatigue strength/density ratio, good thermal stability, excellent resistance to atmospheric corrosion, and can reduce weight. Used in parts below 500°C: compressor plate; stationary blades, moving blades, casing, combustion chamber casing, exhaust mechanism casing, central body, jet pipe, etc.
Body of Aircraft Below 300℃: high specific strength Fire walls, skins, girders, landing gear, wing ribs, bulkheads, fasteners, ducts, hatches, tie rods, etc.
Rocket, Missile and Spacecraft Industry At room temperature and ultra-low temperature, the specific strength is high, and it has sufficient toughness and plasticity High pressure vessel, fuel tank, rocket engine and missile shell, spacecraft rudder skin and structural skeleton, main landing gear, lunar module, etc.
Shipbuilding Industry High specific strength, excellent corrosion resistance in sea water and ocean atmosphere Pressure hull, structural parts, buoyancy system sphere, pump body of watercraft, pipe and deck accessories, speedboat propeller, propulsion shaft, hydrofoil hydrofoil, whip antenna, etc.
Chemical Industry It has good corrosion resistance in oxidizing and neutral media, and can also improve its corrosion resistance through alloying in reducing media In petrochemical, fiber, pulp, fertilizer, acid and alkali, sodium, alkali, chlorine, electrochemistry and seawater desalination industries, it is used as heat exchanger, reaction tower, distiller, washing tower, synthesizer, autoclave, valve, etc. Conduit, pump, pipe, electrolysis electrode, electrolysis cell, anode frame, spinneret, etc.
Other Industry Conventional Weapons Manufacturing Good corrosion resistance and low density Artillery tailstock, mortar floor, rocket gun barrel and chamber, nozzle, artillery hoop, tank wheel, track, torsion bar, tank drive shaft, armor plate, etc.
Metallurgical Industry High chemical activity and good corrosion resistance Used as corrosion-resistant material in the smelting of non-ferrous metals such as nickel, cobalt, titanium, etc., it is a good deoxidizer and alloy element in steel smelting
Medical Hygiene It has excellent corrosion resistance to human body fluids, is non-toxic, and has good affinity with muscle tissue To make medical equipment and surgical orthopedic materials, titanium teeth, heart valves, diaphragms, bone joints and fixation screws, titanium bones, etc.
Ultra-high Vacuum With high chemical activity, it can adsorb oxygen, nitrogen, hydrogen, CO, CO2, methane and other gases Titanium ion pump
